ECP Series Enclosures

High performance, high reliability enclosures for global applications

Featuring an optimized design and fast leadtimes for OEMs, ECP enclosures are available in 40 standard sizes with optional conduit and device drilling and tapping.

Featuring an optimized design and fast leadtimes for OEMs, ECP enclosures are available in 40 standard sizes with optional conduit and device drilling and tapping.

Certifications
NEC, CEC and CSA:

  • Class I, Division 1 & 2, Groups B, C, D
  • Class II, Division 1 & 2, Groups E, F, G
  • Class III • UL Standard 1203
  • cUL to CSA C22.2 No. 30, No. 25
  • NEMA Type 3, 3R, 4, 7BCD, 9EFG
  • Enclosure Type 4X (requires selecting 4X option)

IECEx:

  • Ex db IIB+H2 Gb
  • Ex tb III C Db IP66
  • -20°C ≤ Ta ≤ +60°C
  • IECEx ETL 13.0022U

ATEX:

  • II 2 G D Ex db IIB+H2 Gb
  • Ex tb IIIC Db IP66
  • -20°C ≤ Ta ≤ +60°C
  • ITS13ATEX17813U certified

Standard Materials: Body and cover: copper-free aluminum; gasket: neoprene; cover bolts: steel; hinges: aluminum

Options (add to end of catalog number):

  • ATEX – ATEX certified
  • PLT – Flat aluminum plate cover
  • MP – Aluminum mounting plate installed
  • S391 – NEMA 4X certification with stainless steel cover bolts and hinges
  • S598 – Factory supplied hinges on left side
  • S598B – Factory supplied hinges on top side
  • S598C – Factory supplied hinges on right side
  • S598D – Factory supplied hinges on bottom side
  • S752 – Epoxy powder coat finish on exterior only
  • S753 – Epoxy powder coat finish on interior and exterior
  • S756V – Breather and drain
  • 4X – Type 4X certification, with stainless steel cover bolts, hinges, and external epoxy powder coat
Catalog #: With Mounting Plate:
ECP041604
ECP041604
ECP060804
ECP060806
ECP061204
ECP080806
ECP081006
ECP081204
ECP081206
ECP081208
ECP101006
ECP101008
ECP101406
ECP121204
ECP121206
ECP121208
ECP121806
ECP121808
ECP122408
ECP122410
ECP123608
ECP141406
ECP141408
ECP141410
ECP161606
ECP161608
ECP162408
ECP181806
ECP181808
ECP181810
ECP182408
ECP182410
ECP183008
ECP183608
ECP183610
ECP242408
ECP242410
ECP243008
ECP243608
ECP243610
MP0406
MP0416
MP0608
MP0608
MP0612
MP0808
MP0810
MP0812
MP0812
MP0812
MP1010
MP1010
MP1014
MP1212
MP1212
MP1212
MP1218
MP1218
MP1224
MP1224
MP1236
MP1414
MP1414
MP1414
MP1616
MP1616
MP1624
MP1818
MP1818
MP1818
MP1824
MP1824
MP1830
MP1836
MP1836
MP2424
MP2424
MP2430
MP2436
MP2436

The Only Certified Assembly Partner in the USA & Canada

At Spike Electric Controls, we're not just a Certified Assembly Partner for Eaton’s Crouse-Hinds series products — we are the only one in the USA & Canada. This distinction underscores our unparalleled expertise and commitment to delivering the best in explosion-protected product solutions. Discover our unique partnership with Eaton Crouse-Hinds as the only Certified Assembly Partner in the USA & Canada. For more details and verification, visit Eaton Crouse-Hinds Certified Assembly Partner.



Spike Electric is an Eaton Certified Assembly Partner

Spike is strictly audited and certified by Eaton yearly to ensure they follow all quality and safety standards.

By choosing Spike Electric Controls, you're choosing a partner with a unique position in the industry—a partner verified and backed by Eaton Crouse-Hinds.

Our team's specialized training, certification, and local presence ensure you receive:



  • Unmatched Service & Support
  • Quick & Efficient Logistics: for immediate stock availability.
  • Custom Assembly: of ATEX and IECEx-certified products to your exact specifications.
  • Assurance of Adherence: to the highest quality standards set by Eaton Crouse-Hinds.
  • Annual Audits: confirming our alignment with Hazardous Location Standards.
  • Compliance: with the ISO 9001 Quality Management System, meeting Eaton's rigorous standards.
  • Expertise: from in-house specialized hazardous location engineers.
  • Exclusive In-house Hazardous Location Drilling & Tapping: guaranteeing certified, high-quality processes.
